Orbea Optima E50

Orbea Optima E50
  • Color: Blue
  • Color: Orange
  • Color: Purple
Please select options


Optima is an apparently “normal” bicycle, but both the architecture and the ergonomics of the new Optima are innovative. It is a bike designed to be used as an electric bicycle from the conceptual design phase. This has meant revamping the product to the point that even its architecture changed.

The heart of Optima, the rear hub motor is the key to Optima’s Enough Power concept. The sophisticated drive system provides enough smooth and reliable assistance at levels designed to enhance your ride, not dominate it. And since the motor is at the hub, you’ll experience drag-free pedaling when Optima is not providing a push.

A compact iWoc TRIO controller adds functionality and interaction to Optima, adding more control over the lighting, battery, and assist level of your bike.

The battery is one of the most noticeable components of an eBike system, so every step has been taken to find the lightest, smallest, and most discreet unit. Optimas’s Enough Energy concept provides you enough battery power, not more. It eliminates the need for a bulky, high-output battery that needs to be removed from the bike.

Optima’s smooth and balanced assist requires an advanced sensor. Blending perfectly with our effort to create a sleek and discrete system, the cassette lock ring holds 20 magnets that are detected by the integrated dropout sensor. The system monitors your pedaling input and adjusts power accordingly.

A smartphone and smartwatch-compatible app enables deeper control of the iWoc system used by Optima. Ride tracking, activity, and GPS route uploading and other functions are available from your mobile device, making Optima an even more valuable tool.

- Easy step-through aluminum frame
- 8-speed Shimano Alivio components
- Shimano mechanical disc brakes
- Front and rear dynamo-powered lights
- Fenders, kickstand, and rear rack included


Motor Ebikemotion X35
Battery Ebikemotion 36V/6.9A ANT+
Display Ebikemotion iWoc TRIO
Max Assisted Speed 20mph / 32kph
Charger Ebikemotion X35
Frame Orbea Optima Hydroformed Alloy, Ebikemotion X35 internal battery
Fork Optima 400mm Alloy Post mount
Headset 1-1/8-inch Semi-Integrated
Rims/Wheels Airline Corsa
Tires Kenda 1172 700x50c
Crankset Prowheel PRA105
Chainrings 42T
Chain KMC X8
Rear Derailleur Shimano Altus M310
Cassette/Rear Cogs Shimano HG200 12-32T 8-Speed
Shifters Shimano SL-M315
Handlebars Orbea City Riser Alu 640mm
Stem Orbea TDS-D617
Brake Levers Shimano Alivio BL-T4010
Brakes Shimano TX805 Mechanical Disc
Pedals VP-856 Black
Saddle Selle Royal Milo Plus DR
Seatpost Alloy 31.6x400mm Offset 0
Accessories & Extras SKS EDGE Alloy fenders, front and rear Spanninga dynamo-powered lights, rear rack, kickstand, chain guard

* Subject to change without notice.

Part Numbers

Option UPC MPN Store SKU
Blue / Small 08434446609367 K37717XH
Blue / Medium 08434446609398 K37718XH ORB24348819E
Blue / Large 08434446609428 K37720XH
Orange / Small 08434446609350 K37717XG
Orange / Medium 08434446609381 K37718XG
Orange / Large 08434446609411 K37720XG ORB30517259E
Purple / Small 08434446609343 K37717XF ORB28344084Y
Purple / Medium 08434446609374 K37718XF
Purple / Large 08434446609404 K37720XF
