Details
Wickedly Fast. Ridiculously Fun.
The LES 27.5 is a hardtail aficionado’s dream machine—an ultra-light chassis with BMX-like handling and the rollover advantage of bigger wheels, all in a snappy, fast-accelerating package to fit a wide range of rider sizes. It features new-school hardtail racing geometry with category-redefining short chainstays, allowing the bike to move over trails with a rare agility not often found in serious racing hardtails. With clearance for up to 2.6-inch-wide tires and designed to work with forks from 100–130mm travel, the LES 27.5 is equally at home on a twisting short track as it is through black-diamond terrain. It’s wickedly fun, hyper-capable, and ready for rapid-fire accelerations through rollers, berms, and jumps.
The LES 27.5 is built on an ultra-light, ride-tuned carbon frame featuring leading-edge carbon fiber materials and Pivot’s proprietary hollow core internal molding technology. Specific frame features include the oversized box section downtube and bottom bracket area, tapered head tube, and seat and chainstay shaping designed to reduce rider fatigue and trail vibration. The design incorporates boost 110mm front and 148mm rear dropout spacing. Besides the added clearance for bigger tires, boost spacing allows you to take advantage of wider hubs for stiffer wheels and the most precise handling and responsiveness to rider input. Full-length internal cable routing via Pivot’s exclusive, easy-to-maintain Cable Port System keeps cables clean, quiet, and protected, and allows seamless integration of electronic drivetrains. The LES 27.5 is easily 2x and 1x gearing compatible. For those who love the simple functionality of 1x systems, the removable front derailleur mount offers an incredibly sleek, clean installation with almost no evidence of the un-needed hardware. With a racing pedigree that holds victories in professional races around the world, the LES 27.5 is built to excel.
Pedals sold separately
Specs
Frame | High-modulus carbon fiber, hollow core internal molding technology, Cable Port System |
---|---|
Fork | Fox Factory 32 27.5" - 100mm |
Headset | Pivot Precision Sealed Cartridge - Race |
Axles |
Front: 15 x 110mm Rear: 12 x 148mm |
Rims/Wheels | DT Swiss XMC 1200, 24mm |
Hubs | DT Swiss 240 |
Tires | Maxxis Ikon 27.5 x 2.2" TR, 3C, EXO, MAXXSPEED, 120 TPI |
Crankset | SRAM XX1 Eagle DUB SL |
Chainrings | 32T |
Chain | SRAM XX1 12-Speed |
Rear Derailleur | SRAM XX1 12-Speed |
Cassette/Rear Cogs | SRAM XX1 XG-1299 10-50T |
Shifters | SRAM XX1 12-Speed |
Handlebars | Phoenix Team Flat Carbon - 760mm |
Tape/Grips | Phoenix Team Padloc |
Stem | Phoenix Team XC/Trail |
Brakes | SRAM Guide Ultimate |
Saddle | Phoenix WTB Team Volt |
Seat Post | Please choose seatpost from the drop-down menu |
* Subject to change without notice.
Videos
The Pivot LES 27.5: World Cup Performance
Part Numbers
Option | MPN |
---|---|
Team Blue / Phoenix Team Carbon Rigid (+$0) / X-Small | 19L7CV227CXX1--BLUXSSTDHN |
Team Blue / KS LEV Integra 100mm Dropper (+$310) / X-Small | 19L7CV227CXX1--BLUXS100HN |
Team Blue / Fox Transfer 125mm Dropper (+$310) / X-Small | 19L7CV227CXX1--BLUXS125HN |
Team Blue / Phoenix Team Carbon Rigid (+$0) / Small | 19L7CV227CXX1--BLUSMSTDHN |
Team Blue / KS LEV Integra 100mm Dropper (+$310) / Small | 19L7CV227CXX1--BLUSM100HN |
Team Blue / Fox Transfer 125mm Dropper (+$310) / Small | 19L7CV227CXX1--BLUSM125HN |
Team Blue / Phoenix Team Carbon Rigid (+$0) / Medium | 19L7CV227CXX1--BLUMDSTDHN |
Team Blue / Fox Transfer 125mm Dropper (+$310) / Medium | 19L7CV227CXX1--BLUMD125HN |
Team Blue / Phoenix Team Carbon Rigid (+$0) / Large | 19L7CV227CXX1--BLULGSTDHN |
Team Blue / Fox Transfer 125mm Dropper (+$310) / Large | 19L7CV227CXX1--BLULG125HN |
Westside Red / Phoenix Team Carbon Rigid (+$0) / X-Small | 19L7CV227CXX1--REDXSSTDHN |
Westside Red / KS LEV Integra 100mm Dropper (+$310) / X-Small | 19L7CV227CXX1--REDXS100HN |
Westside Red / Fox Transfer 125mm Dropper (+$310) / X-Small | 19L7CV227CXX1--REDXS125HN |
Westside Red / Phoenix Team Carbon Rigid (+$0) / Small | 19L7CV227CXX1--REDSMSTDHN |
Westside Red / KS LEV Integra 100mm Dropper (+$310) / Small | 19L7CV227CXX1--REDSM100HN |
Westside Red / Fox Transfer 125mm Dropper (+$310) / Small | 19L7CV227CXX1--REDSM125HN |
Westside Red / Phoenix Team Carbon Rigid (+$0) / Medium | 19L7CV227CXX1--REDMDSTDHN |
Westside Red / Fox Transfer 125mm Dropper (+$310) / Medium | 19L7CV227CXX1--REDMD125HN |
Westside Red / Phoenix Team Carbon Rigid (+$0) / Large | 19L7CV227CXX1--REDLGSTDHN |
Westside Red / Fox Transfer 125mm Dropper (+$310) / Large | 19L7CV227CXX1--REDLG125HN |
